When we start talking about motion sensors, we must remember that there is some confusion in terms. The fact is that the actual motion sensors are devices for working as part of security systems. And motion sensors for turning on the light are actually called light sensors, however, in everyday life, both devices are called motion sensors.
What is the main purpose of motion sensors to turn on the light? Comfort? Of course, but first of all, such sensors are installed to save energy. Thanks to them, electricity costs are reduced from 30% to 60%.
Their presence is relevant both in residential and non-residential premises, since the light comes on only when a living object appears in the zone of their action. As soon as the movement stops, after a set time, the light automatically turns off.
Also, the presence of sensors allows you to extend the life of the bulbs, as they work less and burn out less often. Sensors are also convenient in that the light will not be on all the time if you forgot to turn it off and left the house or even left for a long time.
The principle of operation of the sensors is the same regardless of the manufacturer. But they may differ from each other in some characteristics, which must be taken into account depending on the purpose of installing the device.
Which of the motion sensors offered by manufacturers for turning on lights can be considered the best on the market in 2021? By what parameters should you choose it and what to look for?
Editor’s Choice
ORB OB134920
The infrared sensor reacts to the appearance of people or animals. You can program it with the remote control. The device operates from the mains, including lighting when an object is detected within the range. The device can operate at high temperatures (up to 40 º C), the minimum operating temperature is ー10 º C.
The editors chose this sensor as the best for several reasons. First of all, it has high power, which allows you to connect more light sources to it than to other standard sensors. Another major advantage is that it can be placed at a high height, up to 12 m, which means that the sensor can be installed, for example, under the roof of a two-story house. A high degree of moisture protection makes it possible to use the device outdoors (but only in the warm season), and a large 360 ° viewing angle allows you to cover a large area.
Key Features:
| Installation: | open |
| Material: | plastic |
| Maximum power: | 1500 W |
| Width devices: | 140 mm |
| Device Height: | 140 mm |
| Device depth: | 68 mm |
| Wire connection type: | screw |
| Protection class: | IP44 |
| Installation orientation: | horizontal and vertical |
| Adjustment of the threshold for illumination: | Yes |
| Sensitivity threshold adjustment: | Yes |
| Max. frontal range: | 30 m |
| Scan Angle: | 360 ° |
Advantages and disadvantages
Top 10 best motion sensors for turning on lights in 2022 according to KP
1. Legrand 48 946
The device can be installed both indoors and outdoors. Both wall and ceiling mounting is possible. The sensor is equipped with a function to automatically turn on and off the light when it detects a moving object in the coverage area. It has an adjustable time setting during which the light will be on: from 10 s to 10 min. Connection of halogen and LED lamps is possible. The sensor has a maximum viewing angle and a degree of moisture protection.
Key Features:
| Installation: | open |
| Rated voltage: | In 230 |
| Protection class: | IP55 |
| We commute. power: | 1000 W |
| How the motion sensor works: | passive infrared (PIR) |
| Installation height: | 2.5 m |
| Max. frontal range: | 8 m |
| Max. range to the side: | 8 m |
| Scan Angle: | 360 ° |
Advantages and disadvantages
2. IEK LDD 10−010−1100−001
The sensor automatically turns on the load when it detects moving objects within its range. The viewing angle is 180 degrees, the operating range is 10 m. This allows you to cover a fairly large area. The device is temperature resistant and is mainly used outdoors. Can be mounted both on the wall and on the ceiling. The housing is made of fire resistant plastic. However, the sensor power is small, designed for 1-2 light sources.
Key Features:
| Installation: | open |
| Material: | plastic |
| Maximum power: | 0.45 W |
| Width devices: | 63 mm |
| Device Height: | 94 mm |
| Device depth: | 86 mm |
| Protection class: | IP44 |
| Scan Angle: | 180 ° |
Advantages and disadvantages
3. ORBIS OB134312
The ORBIS OB134312 infrared sensor is used to control outdoor and indoor lighting. As soon as a moving object appears in its field of action, the device turns on the light. The sensor is mounted externally with a screw mount and fits perfectly into modern design. Due to its small size it is not conspicuous. The IP55 waterproof rating allows the device to be used outdoors. However, the scanning angle is small: in outdoor placement, it is better to use several sensors if you plan to scan a large area.
Key Features:
| Installation: | open |
| Width devices: | 72 mm |
| Device Height: | 80 mm |
| Device depth: | 100 mm |
| Material: | plastic |
| Protection class: | IP55 |
| Adjustment of the threshold for illumination: | Yes |
| Max. frontal range: | 12 m |
| Max. range to the side: | 8 m |
| Scan Angle: | 140 ° |
Advantages and disadvantages
4. IEK IDD10−009−1100−001
The device is widely used in conjunction with automatic lighting and security systems. Applies the load, detecting movement in the field of action. Wide viewing angle and range allow you to cover a large area. The sensor is made of fire-resistant polycarbonate. Can be used indoors or outdoors. Service life 一 5 years.
Key Features:
| Installation: | on the wall / in the channel |
| Maximum power: | 1100 W |
| Width devices: | 95 mm |
| Device Height: | 80 mm |
| Protection class: | IP44 |
| Scan Angle: | 180 ° |
Advantages and disadvantages
5. Legrand 48945
An infrared sensor is used to control the lighting. The device turns on the light when a moving object appears in its field of action. When used in large rooms, it is desirable to use several sensors, since the scanning angle of the model is small. The device is mounted on the wall, easy to install. Stylish appearance will fit into any interior.
Key Features:
| Installation: | open |
| Rated voltage: | In 230 |
| Material: | plastic |
| Protection class: | IP42 |
| Power: | 1000 W |
| How the motion sensor works: | passive infrared (PIR) |
| Installation height: | 2.5 m |
| Max. frontal range: | 8 m |
| Max. range to the side: | 8 m |
| Scan Angle: | 140 ° |
Advantages and disadvantages
6. REV 28 509 0
The motion sensor is installed in residential premises, entrances of residential buildings, as well as in the corridors of public buildings. Reacts to the movement of an object within a radius of 6 meters, including lighting. The sensor distinguishes the time of day: in the “Sun” mode, the device works around the clock, and in the “Moon” mode only with a certain amount of illumination (total darkness). Operating temperature from -20 to +40 degrees. The device is attached to the ceiling, thanks to which the detection area expands. The low level of moisture protection does not allow the device to be used outdoors.
Key Features:
| Installation: | open |
| Material: | plastic |
| Width devices: | 115 mm |
| Device Height: | 24.3 mm |
| Device depth: | 115 mm |
| Protection class: | IP20 |
| Max. frontal range: | 6 m |
| Max. range to the side: | 6 m |
| Scan Angle: | 360 ° |
Advantages and disadvantages
7. IEK LDD11-024-1100-001
The infrared sensor IEK LDD11-024-1100-001 is designed to control lighting in industrial premises and common areas. The device automatically turns on and off the light, detecting a moving object in the field of action. The time during which the light will be on is adjustable from 5 to 480 s. The body of the sensor is made of non-flammable polycarbonate, which makes its use the safest. The device is recommended to be installed at a height of 2-2,4 m. The scanning angle is 360 degrees, which allows you to cover more area. The service life declared by the manufacturer is 7 years. Warranty period – 1 year.
Key Features:
| Installation: | open |
| Mount type: | screw |
| Width devices: | 115 mm |
| Device Height: | 115 mm |
| Device depth: | 58.8 mm |
| Protection class: | IP3X |
| Max. power: | 1 W |
| Installation height: | 4 m |
| Max. frontal range: | 6 m |
| Max. range to the side: | 6 m |
| Scan Angle: | 360 ° |
Advantages and disadvantages
8. REV 15 283 5
The device is the best option for installation in entrances, summer cottages, industrial premises and bathrooms. The sensor automatically turns on the light when heat sources are detected. The high degree of protection allows the device to be used both indoors and outdoors. Lighting turns off automatically after the set time has elapsed, which allows significant energy savings. Universal black color will fit into any design and will not attract too much attention.
Key Features:
| Installation: | open |
| Material: | plastic |
| Width devices: | 98 mm |
| Device Height: | 60 mm |
| Device depth: | 87 mm |
| Protection class: | IP44 |
| Max. frontal range: | 12 m |
| Scan Angle: | 110 ° |
Advantages and disadvantages
9. IEK DD 035
The device is of the built-in type, that is, it is mounted instead of a standard switch. The sensor automatically turns on the lighting when it enters the viewing radius of a moving object. You can also set the sound signal. Withstands temperatures from -25 to +40 degrees. Viewing range 一 12 m. Such a sensor can only be installed indoors.
Key Features:
| Installation: | hidden |
| Material: | plastic |
| Width devices: | 80 mm |
| Device Height: | 80 mm |
| Device depth: | 57 mm |
| Wire connection type: | screw |
| Protection class: | IP20 |
| Installation orientation: | horizontal |
| Max. frontal range: | 12 m |
| Scan Angle: | 140 ° |
Advantages and disadvantages
10. EKFMS-19B
The built-in sensor is suitable for use in offices, homes and industrial premises. The device responds to movement. When a living object enters the sensor field, the sensor turns on the lighting. After a while, the light turns off, which allows you to significantly save energy. For ease of setup, the connection diagram is indicated directly on the product case. The moisture protection class is low, so the sensor can only be used indoors.
Key Features:
| Installation: | hidden |
| Material: | plastic |
| Installation height: | 1,4 m |
| Protection class: | IP20 |
| Max. frontal range: | 6 m |
| Max. range to the side: | 6 m |
| Scan Angle: | 120 ° |
Advantages and disadvantages
How to choose a motion sensor
For help in choosing a motion sensor to turn on the light, Healthy Food Near Me turned to an expert – electrical engineering on local networks at commercial and industrial facilities to Yuri Slepukhov.
Popular questions and answers
2. The next option is operating range. Here you need to focus on the distance at which the sensor will have to work.
3. Next is viewing angle. Here everything will depend on the location of the sensor. If it will be installed in a narrow room, such as a corridor, a small angle is sufficient. If in a large wide room with several inputs, then one sensor with a large angle, preferably 360 degrees, otherwise there will be uncovered areas and errors in operation.
4. You also need to pay attention to whether there is adjustable sensitivity level. The presence of this function is important when installing in a room where there are animals. When installing the sensor outdoors, the presence of this function is always important, otherwise the device will be triggered even by small moving objects, such as frogs or mice.
5. Next – мощность. The higher it is, the more light sources can be connected to the sensor at the same time.
6. And the last thing you need to pay attention to – light level adjustment. If there is no regulator, the sensor can only be installed where the light level is the same throughout the day. For example, in blind corridors, staircases without windows, basements, etc.
As a standard, motion sensors are installed at the entrances above the doorways or on the ceiling above the door. One sensor is enough for each input. Devices are also installed on stairs, on each flight and in walk-through rooms, for example, corridors. The required number of sensors will depend on the layout features, for example, if there are corners and turns, it must be taken into account that the sensor will not respond to a moving object outside the zone of its sensitivity angle.
When installing motion sensors, it is important to exclude objects from their detection zone that can lead to erroneous operation – air conditioners, fans, etc.
There are also devices that include several motion sensors and a control unit. They integrate with each other and work co-dependently. If one of the sensors is triggered, the signal is transmitted to the control unit, and all lighting devices connected to this unit are turned on.
When installing the device on the street, the desired angle of its sensitivity will depend on the design features of the buildings. Depending on this, you will need one or more sensors.
Motion sensors differ among themselves in the way of installation: overhead and built-in. Provided that the characteristics of the devices are the same, the choice can be guided only by the design.
Detailed instructions for adjusting the sensor can be found in the user manual that comes with the kit. But, according to the expert, for the correct operation of the device, a specialist must install and configure it.
