Euronova washing machine error codes – how to fix

The modern washing machine Euronova (Eurosoba), like other machines, provides a self-diagnosis system. This system finds breakdowns and issues error codes on the electronic scoreboard.

Euronova washing machine error codes - how to fix

The user, understanding what the code means, can often fix the problem himself without resorting to the services of specialists.

If an error appears on the scoreboard, the work of SM Evronov is blocked, and often the code does not disappear from the screen even after a reboot. To remove the error, you need to do this:

  1. Turn the selector wheel to the “asterisk” position.
  2. Turn the selector switch to P2 “Cold”.
  3. Hold down two buttons at once – the second and thirdEuronova washing machine error codes - how to fix . Keep your fingers on the buttons until the code disappears from the display.
  4. If errors have been reset, the combination “00” will appear on the display, which means that the machine is ready for use.
  5. If the machine gives an error again when starting the washing programs, it needs to be repaired.

Next, we will consider what to do if the Euronov machine shows an error, and how to fix the malfunction that caused it.

Error table Eurosoba washing machine: what they mean and how to fix

Error codeDescription of the problemPossible causes of SM breakdowns Euronova (Eurosoba) – for models 1100 Sprint, 1100 Sprint +
F1The machine is on but does not wash.If the F1 error is on, there can be three reasons for this:
  • Broken door lock. Item needs to be replaced.
  • The microswitch is broken. It is necessary to check its contacts, isolate or replace damaged areas. If the problem persists, replace the blocker (UBL).
  • Control unit failure. Replacing burnt and failed sections of the board or a complete replacement of the unit is required.
F2The operation of the SMA drain system is disrupted. There is either no drain or the water drains too slowly.What to do with F2 error:
  1. Clean the drain pump filter.
  2. Check that the drain hose is installed correctly. It should be at a height of 50 cm from the floor. Proceed according to the diagram shown in your user manual.
  3. Check drain hose. It may have twisted, been pinched, or clogged. Return the hose to its normal position, clean and rinse.
  4. Repair (check the contacts, clean the filter) or replace the drainage pump (pump) CM Euronova.
F3Filling system failure. Water is not poured into the tank at all or is drawn too slowly.

How to fix F2 error? If low pressure in the water supply system is to blame for the failure, you need to normalize the water pressure.

Other causes of failure:

  • The water valve is closed, or the filler valve of the machine is closed. Open them.
  • The mesh filter installed at the point where the inlet hose is attached to the CM body is clogged. Clean and wash the filter.
  • The contacts on the terminals of the solenoid valve of the water inlet are broken. Or they burned out, the contacts of the pressure switch (level sensor) oxidized.
  • The water pressure (level) sensor has broken. The sensor needs to be replaced.
F4Breakdown of the filling system: too much water is collected, after which the wash does not start.In error F6, the following factors may be to blame for the breakdown of the filling system:
  1. The level sensor is broken. It is necessary to repair its hydraulic system or replace the sensor with a new original part.
  2. Solenoid filling valve blocked. The valve needs to be cleaned.
  3. Malfunction of the control unit. It needs to be repaired or completely replaced.
F5Breakdown in the heating system of the Eurosoba brand washing machine. Washing goes in cold water.In the occurrence of error F5, only two breakdowns can be involved:
  • The temperature sensor control circuit is broken. To verify this, you need to check its contacts and eliminate the breaks.
  • The thermistor (temperature sensor) is broken. It can be either an open or a short circuit. In this case, you need to replace the temperature sensor SM Evronov.
F6It also indicates a malfunction in the heating system. Washing water does not heat up.When CMA shows F6 on the display, it means:
  1. The contacts of the tubular electric heater are oxidized or burnt out. You need to inspect and clean the contacts.
  2. The heater itself broke. You need to check it with a tester, descale or completely replace the element.
F7Damage to the drain and fill systems. The tank is full, water is pouring out of it.If F7 is displayed on the scoreboard, then:
  • The pressure switch broke. It needs repair or replacement.
  • The water pump has broken. Checking the contacts, cleaning the filter or completely replacing the pump will help.
  • Malfunction of the control unit. The solution to the problem lies in replacing individual sections of the board or completely reinstalling the unit.
F8Electric motor breakdown. The motor does not rotate at all or rotates at insufficiently high speeds.With an F8 error, you can diagnose the following breakdowns:
  1. Malfunction of the tachogenerator. In this case, the spring washer could come off its place. To fix the failure, you need to return the location of the tachogenerator magnet.
  2. The connection between the TACHO unit, the control unit and the electric motor is broken. In this case, you need to service the wiring and terminals (replace damaged parts) to restore communication.
  3. The motor winding is burned out or the brushes are worn out. If it’s just the brushes, they need to be replaced. If the engine has exhausted its resource, you need to replace the electric motor.
  4. The TAHO unit broke. It is necessary to completely replace the ED-TAHO unit.
F9Failure of the electric motor. The engine is spinning too fast, exceeding the permissible number of revolutions.With code F9, there are 2 possible causes of failure:
  • Failure in the ED control unit. It is required to replace the burnt triac of the board.
  • The controller is broken. The unit needs to be repaired or replaced.
F11The machine does not start when any wash mode is selected.There are at least 4 reasons that could cause the F4 error code to appear on the scoreboard:
  1. Sunroof not closed tightly enough. Try closing it tighter.
  2. Breakage of the hatch lock latch. Replace the lock if it cannot be repaired.
  3. UBL contact defects. Get them serviced.
  4. Violations in the electrical circuit of the blocker. It is necessary to inspect the contacts and, having found breaks, eliminate them. If that doesn’t work, replace the lock.
FCDrainage system failure. The machine stops working, leaving water in the tank.FS lights up on the CMA screen in such cases:
  • In the event of a breakdown in the drain pump circuit. Checking of all wiring coming from the pump is required. Find the break and fix it. If that doesn’t work, replace the pump.
  • The pump impeller has failed. In this case, you will have to change the drainage pump completely.
  • The pump is clogged. You need to get the pump and clean it of small debris and dirt. Also clean the filter.

The fault codes on the screen of your Euronova washer will always help you figure out the problem – keep the plate for yourself so that it is at hand.
